48PT2
The 48PT2 scanner comes with cables rated for tray cable - exposed run (TC-ER) and complies with the crush and impact requirements of the standard for metal clad cable, UL 1569.
48PT2
The 48PT2 lead sulfide infrared scanner contains a low impedance detector and is designed to detect low flicker frequency IR signals from gas and oil flames. It is designed for use on D-Series, Flame- Monitor, FlameWorx, MicroM and Burnerlogix controls.
48PT1 (Obsolete)
The 48PT1 lead sulfide infrared scanner contains a high impedance detector and is designed to be used only on P-Series controls.
Features
- IR flicker detector
- Low voltage, typically 7-15VDC across the Cell
- For gaseous,oil and solid fuels
- Single burner and Gas Turbine applications
- Suitable >24hr operation
- Used with Fireye controls FlameMonitor, Flameworx, BurnerLogix, D-Series
- Powered by control
- Temperature range -40 to +60°C
- Explosion proof housing available ATEX Ex d IIC T6
IR Scaner Models
|
Part Number |
Description |
Manual Number |
|
|
|
|
|
48PT2-1003 |
Infrared scanner, 8', straight head, BurnerLogix, E-Series, MicroM |
SC-103 |
|
48PT2-1007 |
Infrared scanner, 4', straight head, BurnerLogix, E-Series, MicroM |
SC-103 |
|
48PT2-1016 |
Infrared scanner, 16', straight head, BurnerLogix, E-Series, MicroM |
SC-103 |
|
48PT2-1030 |
Infrared scanner, 30', straight head, BurnerLogix, E-Series, MicroM |
SC-103 |
|
48PT2-9003 |
Infrared scanner, 8', 90 degree head, BurnerLogix, E-Series, MicroM |
SC-103 |
|
48PT2-9007 |
Infrared scanner, 4', 90 degree head, BurnerLogix, E-Series, MicroM |
SC-103 |
|
48PT2-9016 |
Infrared scanner, 16', 90 degree head, BurnerLogix, E-Series, MicroM |
SC-103 |
|
48PT2-9007W |
Replaced with 48PT2-9007 |
SC-103 |
Explosion Proof Scanners Models
|
Part Number |
Description |
Manual Number |
|
|
|
|
|
48PT2-CEX |
Cenelec EExd IIC explosion proof housing with 48PT2 scanner. |
SC-103 |
|
60-2928-9 |
Replacement scanner for the 48PT2-CEX |
SC-103 |
Fibre Optic Kit Models
|
Part Number |
Description |
Manual Number |
|
|
|
|
|
IRFK-3 |
Infrared fiber optic kit, used with 48PT2 scanners. Includes mounting block and 3 foot fiber optic bundle. |
SC-103 |
|
IRFK-5 |
Infrared fiber optic kit, used with 48PT2 scanners. Includes mounting block and 5 foot fiber optic bundle. |
SC-103 |
Spare Detection Cells Models
|
Part Number |
Description |
Manual Number |
|
|
|
|
|
4-128-1 |
Firetron cell for 48PT1 only. |
SC-103 |
|
4-263-1 |
Firetron cell for 48PT2 only. |
SC-103 |
